F1 Basic

Article number: 421.000.000

The F1 basic is for flexo printing only, a universal flexo tester for use with solvent based inks, UV inks and water inks on a range of substrates.

The IGT F1 Basic is equipped with a number of preset / pre-selected standard printing conditions that will cover the most common test applications. This makes the F1 Basic a very user-friendly, reliable and consistent printability tester for flexo. The IGT F1 Basic ensures consistent results due to simple operation, low maintenance and high accuracy.

•High reproducibility
•Simple to operate
•Consistent results

Inking and printing sections
• Electronic control of printing force and speed
• Printing speed:
0,3; 0,6; 0,9 m/s (F1 Basic)
• Anilox/printing force:
– 20/30; 40/60; 60/90 N (F1 Basic LOW)
– 100/150; 200/300; 300/450 N (F1 Basic HIGH)
• Maximum substrate thickness: 4 mm

• Printing width on substrate: 40 mm

• Print length ca. 500 mm
• Anilox- or engraved disc is inked automatically up to 20 times
• Photopolymer printing form can be inked up to 20 times
• Flexo and gravure modes (F1 Basic flexo mode only)

Doctor blade
• Doctor blade angle: 60°, trailing
• Doctor blade pressure: 6 – 7 N
(12 – 14 N for F1-100)

• Flexo aniloxes
–  copper engraved, chromium
plated, solid and 4 engravings
–  Ceramic, laser engraved, solid
– Range of volumes
• Modern styling
• Simple operation; touch screen
• Reliable
• Low initial cost
• Possible to use many substrates and inks

Weight : 35 kg (60 kg for F1 UV)
Height : 350 mm
Width : 600 mm
Depth : 350 mm

Electrical connection:
90 – 245 V / 50 – 60 Hz

Dimensions(L x W x H):0cm x 0cm x 0cm
Main application:
Conformance with standards/W-leaflet:
Water bath and temperature:
Speed range and modes:
Substrate requirements:
Interval time and number:
Printing shafts type and options:
Shaft positioning:
Lifting system:
Print length and width:
Printing discs:
Sector positioning:
Sector type and options:
Doctoring system:
Dispensing system:
Pre-programmed tests:
Analysis options:
Software updates:
Data export options:
Additional items:
Inks or liquids:
Inking speeds:
Inking programs:
Top rollers:
Compatible instruments:
Measurement range:
Light source/ power/angle:
Shelf life:
Use life:
Description of property:
Power Supply Requirements:
Space requirements:
Standard delivery time:1-2 weeks
